MOTU 828 USB 3.0 Audio Interface

28-in/32-out USB3 Audio Interface with 24-bit/192kHz Conversion, 3.9″ TFT Display, 2 Mic Preamps, 24-channel Digital Mixer, and DSP Effects – Mac/PC/iOS

SKU: MOTU 828

100% Genuine Products Only

We sell the products from the world's renowned brands only.

Talk to our Sales Expert

Available on backorder

Add to compare

Add to wishlist

11 People watching this product now!

Self-pick-up from our Shop

Pick up from our Bouddha Store

Free

Delivery within the Kathmandu Valley

Our courier will deliver to the specified address

1-12 Hours

Pathao/Indrive

Courier delivery

Aramex courier will deliver to your specified address

1-2 Days

"Fees vary based on geographical location."

Warranty 1 year

More details

Genuine & Original Product

More details

Payment Methods:

Description

With the MOTU 828 USB 3.0 Audio Interface , MOTU’s legendary audio interface has been retooled with an ESS Sabre32 DAC and dual full-color displays. This interface delivers pristine audio playback, with an outstanding 123dB of dynamic range. Its recording performance is just as impressive, with round-trip latency as low as 1.6ms at 96kHz. A superb complement of I/O includes 60 simultaneous audio channels, two great-sounding mic preamps, a range of digital options, and AVB networking. Employ the 828es as a standalone mixer, or enjoy wireless control from your tablet, smartphone, and laptop. The 828es’s powerful DSP-driven mixer gives you 48-channel mixing, along with a range of great-sounding digital effects. The 828es makes a fine centerpiece for any studio.

High-end converters, ultra-low latency, and ample I/O offer top-shelf performance

MOTU have enjoyed a long-standing relationship, due to MOTU’s products offering our customers superb sound and solid performance. The 828es follows suit, packing top-notch sound, impressively low latency, and ample I/O into a single-rack enclosure. Renowned ESS Sabre32 DAC technology delivers 123dB of dynamic range, ensuring that the 828es’s analog audio quality can hang with the most impressive gear on the market. Optimized drivers yield round-trip latency as low as 1.6ms at 96kHz via Thunderbolt and 1.9ms via USB. Packed with connectivity, the 828es includes two mic preamps, eight analog inputs, eight analog outputs, two analog XLR outputs, and a pair of stereo headphone outputs. The 828es also supplies you with 16 channels of ADAT, as well as stereo S/PDIF, MIDI, and word clock I/O.

DSP-fueled mixer with EQ, compression, and effects

The MOTU 828es’s built-in digital mixer delivers large-console-style mixing with 48 channels, 7 stereo buses, 3 groups, access to 32 network inputs, and 32-bit floating-point effects processing, so building complex, latency-free routing schemes is a piece of cake. And routing is extremely flexible. Send any input to any output, or even multiple outputs. Add Classic Reverb, with lengths up to 60 seconds. Sculpt your sound with a 4-band British parametric EQ. Apply vintage compression that’s modeled after the legendary LA-2A. The 828es’s mixing and effects DSP engine exhibit virtually unlimited headroom and outstanding sound quality.

Apple Thunderbolt Display not included.

828 USB 3.0 Audio Interface

Control everything from your laptop, tablet, or smartphone

If you connect a wireless router to your 828es, you can access all of its internal mixing functions, including effects and processing on your tablet, smartphone, or laptop, turning this powerful audio interface into a fully capable standalone mixer. Best of all, the control software is web-based. It runs in your favorite web browser on Mac, Windows, Linux, iOS, or Android — basically anything — as long as it’s on the same network.

828 USB 3.0 Audio Interface

Expand your system with additional AVB networkable audio interfaces

Another extremely cool use of the MOTU 828es Audio Interface Ethernet connection is the ability to link more MOTU AVB-equipped audio interfaces to it. You can do this in one of two ways: directly via a simple Ethernet cable or as part of an audio network via one or more MOTU AVB Switches. If you go with just a single Ethernet cable, you can easily link a second 828es or other AVB-ready device directly to your first one. With MOTU AVB Switches, you can create an audio network of up to five units, potentially linking hundreds of channels of I/O across multiple rooms. And since it’s all over standard Cat-5e Ethernet cable, latency and long cable runs aren’t an issue.

Mac System Requirements

1 GHz Intel-based Mac or faster
2 GB RAM; 4 GB or more recommended
Mac OS X version 10.8 or later
Available Thunderbolt 1/2/3, USB 2/3 or AVB/TSN Ethernet port*
A large hard drive (at least 500 GB for recording)
*AVB/TSN Ethernet audio interface operation requires OS X El Capitan or later

Windows System Requirements

1 GHz Pentium-based PC compatible or faster
2 GB RAM; 4 GB or more recommended
Windows 7, 8 or 10
Available Thunderbolt 1/2/3 or USB 2/3 port
A large hard drive (at least 500 GB for recording)

Web App Suppor

Any web client platform: Mac, Windows, Linux, iOS, Android
Any web browser: Safari, Firefox, Chrome, Opera, Explorer, etc.

Operating Systems

For computer audio I/O: Mac OS X 10.8 or later; Windows 7 or later
For web app control: Mac, Windows, Linux, iOS, Android

828 USB 3.0 Audio Interface Features:

28-in/32-out hybrid audio interface for studio and live sound
ESS Sabre32 DAC technology delivers 123dB of dynamic range and superb audio quality
Optimized drivers yield round-trip latency as low as 1.6ms at 96kHz via Thunderbolt and 1.9ms via USB
Dual LCD screens allow you to see all signal activity at a glance with detailed metering
Access your hardware settings from a simple and convenient front-panel menu
2 great-sounding microphone preamps with dedicated sends, switchable pads, and phantom power
8 analog inputs accommodate a wide variety of line-level gear
16 channels of ADAT optical digital I/O and stereo S/PDIF expand your system with additional gear
Built-in talkback mic with front-panel Talk button and A/B speaker select buttons
Onboard 32-bit floating point DSP-driven digital mixer with EQ, dynamics, and effects provides latency-free routing
Hook up a wireless router and take complete control of the onboard mixer from your laptop, tablet, or smartphone
MOTU’s AVB audio networking expands your system with additional AVB-equipped audio interfaces
Create an AVB network via optional AVB Switches with support for up to 5 compatible interfaces

With a commitment to provide top-notch customer service and competitive prices, Audio Shop Nepal is the go-to destination for many audio enthusiasts in Nepal looking to purchase Motu products.

Specification

Computer Connectivity:USB 3.2 Gen 1
Form Factor:Rackmount
Simultaneous I/O:28 x 32
Number of Preamps:2
Phantom Power:Per channel
A/D Resolution:Up to 24-bit/192kHz
Analog Inputs:2 x XLR-1/4" combo (mic/line/Hi-Z), 8 x 1/4" (line)
Analog Outputs:8 x ¼" TRS (line, DC coupled), 2 x XLR (main out)
Digital Inputs:1 x Coax (S/PDIF), 1 x Optical A (ADAT), 1 x Optical B (ADAT/stereo Toslink)
Digital Outputs:1 x Coax (S/PDIF), 1 x Optical A (ADAT), 1 x Optical B (ADAT/stereo Toslink)
Inserts:2 x 1/4" TRS (mic send), 2 x 1/4" TRS (mic return)
Headphones:2 x 1/4" TRS (ESS-driven)
MIDI I/O:In, Out/Thru
USB:1 x USB-C 3.2 Gen 1
Clock I/O:1 x BNC (In, Out/Thru)
Other I/O:1 x 1/4" (footswitch)
Features:3.9" LCD Display
Software:MOTU CueMix 5 app, MOTU Performer Lite, Ableton Live Lite
OS Requirements - Mac:macOS 10.13 or later
OS Requirements - PC:Windows 10 or later
Rack Spaces:1U
Power Supply:Standard IEC AC cable
Height:1.75"
Width:19"
Depth:12.25"
Weight:11 lbs.
