MOTU 24Ao USB / AVB / iOS Interface

Audio Interface with 24 analog channels in one rack space, superb audio quality, AVB audio networking and large console style mixing with 48 channels and 12 stereo busses

Brand: Motu

100% Genuine Products Only

We sell the products from the world's renowned brands only.

Talk to our Sales Expert

Available on backorder

Compare

Add to wishlist

12 People watching this product now!

Self-pick-up from our Shop

Pick up from our Bouddha Store

Free

Delivery within the Kathmandu Valley

Our courier will deliver to the specified address

1-12 Hours

Free

Courier delivery

Aramex courier will deliver to your specified address

1-2 Days

Free

Warranty 1 year

More details

Genuine & Original Product

More details

Payment Methods:

Description

Like the rest of MOTU’s popular AVB-equipped audio interfaces, the MOTU 24Ao Audio Interface lets you send a ton of audio across a standard network and get low latency, high quality, and powerful DSP mixing options. This 24Ao was designed with line-level output in mind, and it’s 24 channels of analog output are ideal if you need to send audio to your front-of-house mixer, your studio processing rig, or your analog summing amplifier. The internal mixer includes all kinds of DSP processing, summing, and routing options too, and between its high-speed USB 2.0 connectivity and additional 24 channels of ADAT optical I/O, the MOTU 24Ao fits into any kind of audio rig.

Tons of high-quality connections packed into a single-rackspace audio interface

It doesn’t matter if you prefer DB-25 D-subs or Phoenix plugs, the MOTU 24Ao makes connecting up to 24 analog line channels a piece of cake. Capable of 123dB of dynamic range, the 24Ao is the perfect last step in the digital signal path before your analog summing mixer, live mixing console, studio racks, or any number of other audio destinations. What’s more, there are three pairs of ADAT optical ports onboard, offering an additional 24 channels of digital I/O via USB 2.0 or AVB network.

DSP-fueled mixer onboard gives you the added benefit of EQ, compression, and effects

In many situations, the MOTU 24Ao’s integrated DSP mixer is beneficial. First, this digital mixer offers up to 48 inputs and 12 stereo buses, letting you create complicated routing schemes without a computer. If you connect a wifi network to your 24Ao, you may use an iOS app to access all of its internal mixing features, including effects and processing, converting it into a standalone mixer. The 24Ao’s DSP EQ, compression, gate, and reverb are useful in the studio and onstage.

Expand your production system with additional AVB networkable audio interfaces

Connecting multiple MOTU AVB audio interfaces to the 24Ao via Ethernet is another amazing feature. Directly via Ethernet cable or as part of an audio network using one or more MOTU AVB Switches. With one Ethernet cable, you may connect a second 24Ao or other AVB-ready device to your first. Up to five MOTU AVB Switches may establish an audio network with hundreds of I/O channels across numerous rooms. Latency and cable runs don’t matter as it’s all over Cat-5e Ethernet cable.

Mac System Requirements

1 GHz Intel-based Mac or faster
2 GB RAM; 4 GB or more recommended
Mac OS X version 10.8 or later
Available high-speed USB 2.0 or AVB Ethernet port*
A large hard drive (at least 500 GB for recording)
*AVB Ethernet audio interface operation requires OS X Yosemite

Windows System Requirements

1 GHz Pentium-based PC compatible or faster
2 GB RAM; 4 GB or more recommended
Windows 7, 8 or 10
Available USB 2.0 or 3.0 port
Available Ethernet port for firmware updates
A large hard drive (at least 500 GB for recording)

Web App Support

Any web client platform: Mac, Windows, Linux, iOS, Android
Any web browser: Safari, Firefox, Chrome, Opera, Explorer, etc.
Web client must be connected to the same network as the MOTU AVB interface by wire or Wi-Fi.

MOTU 24Ao Audio Interface Features:

A versatile 24-in/48-out network audio interface for studio and live sound applications
Choose from ultra-low-latency Thunderbolt, high-speed USB 2.0, or iPad/iOS (w/ Camera Connection Kit) connectivity
24 high-quality analog outputs are available on both DB-25 D-sub connectors and Phoenix connectors
24-channels of ADAT optical digital I/O lets you expand your system with additional gear
Onboard 32-bit floating point DSP-driven digital mixer with EQ, dynamics, and effects provides latency-free routing
Hook up a wireless router and take complete control of the onboard mixer from your iOS device – no computer needed!
AVB audio networking lets you easily expand your system and additional AVB equipped audio interfaces
Create an AVB network via optional AVB Switches for support for up to five compatible interfaces

With a commitment to provide top-notch customer service and competitive prices, Audio Shop Nepal is the go-to destination for many audio enthusiasts in Nepal looking to purchase Motu products.
