MOTU 24Ai USB / AVB / iOS Interface

Whether you’re recording in the studio, taking direct output feeds off of an analog mixer, or capturing audio onstage, the MOTU 24Ai USB 2.0 audio interface gives you the high channel count and low latency you need. Like the rest of MOTU’s popular AVB-equipped audio interfaces, the 24Ai lets you send a ton of audio across a standard network. The internal mixer also includes all kinds of DSP processing, summing, and routing options too, and between its high-speed USB 2.0 connectivity and additional 24 channels of ADAT optical I/O, you can easily expand the capabilities of your MOTU 24Ai.

MOTU 24Ai AVB Network/USB 2.0/iOS Audio Interface at a Glance:

• Tons of high-quality connections packed into a single-rackspace audio interface
• DSP-fueled mixer onboard gives you the added benefit of EQ, compression, and effects
• Expand your production system with additional AVB networkable audio interfaces

Tons of high-quality connections packed into a single-rackspace audio interface

The MOTU 24Ai allows connecting 24 analogue line channels easy using DB-25 D-subs or Phoenix plugs. The A24i is perfect for collecting live signal or taking direct outputs from an analogue mixing console. Three pairs of ADAT optical ports provide 24 digital I/O channels through USB 2.0 or AVB network.

DSP-fueled mixer onboard gives you the added benefit of EQ, compression, and effects

The MOTU 24Ai’s onboard DSP mixer offers a number of advantages you’ll find useful in a variety of settings. For starters, this digital mixer supports up to 48 inputs and 12 stereo busses, allowing you to set up extremely complex routing schemes completely independent of your computer. In fact, if you connect a wireless router to your 24Ai, you can access all of its internal mixing functions, including effects and processing, via an app on your iOS device, turning this powerful audio interface into a fully capable standalone mixer. Speaking of onboard processing and effects, whether you’re in the studio or onstage with your 24Ai, you’ll find a ton of uses for its DSP EQ, compression, gate, and reverb.

Expand your production system with additional AVB networkable audio interfaces

Another extremely cool use of the 24Ai’s Ethernet connection is the ability to link more MOTU AVB equipped audio interfaces to it. You can do this in one of two ways: directly via a simple Ethernet cable or as part of an audio network via one or more MOTU AVB Switch. If you go with just a single Ethernet cable, you can easily link a second 24Ai or other AVB ready device directly to your first one. With MOTU AVB Switches, you can create an audio network of up to five units, potentially linking hundreds of channels of I/O across multiple rooms. And since it’s all over standard Cat-5e Ethernet cable, latency or cable runs aren’t any kind of issue.

Mac System Requirements

• 1 GHz Intel-based Mac or faster
• 2 GB RAM; 4 GB or more recommended
• Mac OS X version 10.8 or later
• Available high-speed USB 2.0 or AVB Ethernet port*
• A large hard drive (at least 500 GB for recording)
• *AVB Ethernet audio interface operation requires OS X Yosemite

Windows System Requirements

• 1 GHz Pentium-based PC compatible or faster
• 2 GB RAM; 4 GB or more recommended
• Windows 7, 8 or 10
• Available USB 2.0 or 3.0 port
• Available Ethernet port for firmware updates
• A large hard drive (at least 500 GB for recording)

Web App Support

• Any web client platform: Mac, Windows, Linux, iOS, Android
• Any web browser: Safari, Firefox, Chrome, Opera, Explorer, etc.
• Web client must be connected to the same network as the MOTU AVB interface by wire or Wi-Fi.

MOTU 24Ai Audio Interface Features:

• A versatile 48-in/24-out network audio interface for studio and live sound applications
• Choose from ultra-low-latency Thunderbolt, high-speed USB 2.0, or iPad/iOS (w/ Camera Connection Kit) connectivity
• 24 high-quality analog inputs are available on both DB-25 D-sub connectors and Phoenix connectors
• 24-channels of ADAT optical digital I/O lets you expand your system with additional gear
• Onboard 32-bit floating point DSP-driven digital mixer with EQ, dynamics, and effects provides latency-free routing
• Hook up a wireless router and take complete control of the onboard mixer from your iOS device – no computer needed!
• AVB audio networking lets you easily expand your system and additional AVB equipped audio interfaces
• Create an AVB network via optional AVB Switches for support for up to five compatible interfaces
