Marantz Professional Rack Mix 12 12 Channel Line Mixer

Marantz Professional Rack Mix 12 Line Mixer

The Rack Mix 12 is a 1U rack-mounted 12-channel mixer that can solve countless audio challenges. It features 6 mic/line combination inputs.

SKU: Professional Rack Mix 12

100% Genuine Products Only

We sell the products from the world's renowned brands only.

Talk to our Sales Expert

Available on backorder

Add to compare

Add to wishlist

20 People watching this product now!

Self-pick-up from our Shop

Pick up from our Bouddha Store

Free

Delivery within the Kathmandu Valley

Our courier will deliver to the specified address

1-12 Hours

Pathao/Indrive

Courier delivery

Aramex courier will deliver to your specified address

1-2 Days

"Fees vary based on geographical location."

Warranty 1 year

More details

Genuine & Original Product

More details

Payment Methods:

Description

The Marantz Professional Rack Mix 12 Line Mixer is a 1U rack-mounted 12-channel mixer that can solve countless audio challenges. It has 6 HDHQTM Denon-Marantz proprietary mic pre’s with switchable phantom power and 6 line-level inputs. It features balanced XLR outputs, a 1/4-inch (6.3mm) mono output to link the Rack Mix 12 to a remote mixer, RCA stereo outputs to connect to a remote recording device, and a mic monitoring connector to monitor mic signals. The Rack Mix 12 has master, mono output, and input level controls. A 3-level equaliser and Mic/Line 1 priority complete the features. From a classroom to a tour van, it may be powered by AC or 24V DC.

Rack Mix 12 Line Mixer Highlights;

6 HDHQ^™ Combination inputs with MIC, Phantom and Line selector switches
6 mono (3 stereo) RCA Inputs
Mic monitor ¼” output for private listening to all mic inputs
Balanced XLR line outputs
Mono ¼” line output can be used to feed audio to external recording device
AC or 24V DC power inputs
Mic 1 Priority Control
Master and Individual level controls
1U rack mountable

With a commitment to provide top-notch customer service and competitive prices,Audio Shop Nepal is the go-to destination for many audio enthusiasts in Nepal looking to purchase Marantz products.

Specification

Microphone Input (Channels 1–6)

Connectors: 6 Balanced XLR
Frequency Response: 20 Hz - 22 kHz
THD+N: < 0.03% @ 1 kHz
Sensitivity: -40 dBu
Maximum Input: -19 dBu
Maximum Voltage Gain:
- Rec Out: 50 dB
- Line Out, Mic Out & Mono Out: 60 dB
Signal-to-Noise Ratio: > 103 dB
Phantom Power: 18–21 V, switch-controlled

Line Inputs (Channels 1–6)

Connectors: 6 Balanced XLR
Frequency Response: 20 Hz - 22 kHz
THD+N: < 0.03% @ 1 kHz
Sensitivity: 0 dBu
Maximum Input: +21 dBu
Maximum Voltage Gain:
- Rec Out: 10 dB
- Line Out, Mic Out & Mono Out: 20 dB
Signal-to-Noise Ratio: > 103 dB

Line Inputs (Stereo RCA Connectors, Channels 7/8-11/12)

Connectors: Balanced RCA
Frequency Response: 20 Hz - 22 kHz
THD+N: < 0.03% @ 1 kHz
Sensitivity: +10 dBu
Maximum Input: +21 dBu
Maximum Voltage Gain:
- Line Input to Line Out: 10 dB
- Line Input to Rec Out: 0 dB
- Line Input to Mono Out: 4 dB
Signal-to-Noise Ratio: > 103 dB

Impedance

Mic/Line Input: 1.4 kΩ
Line Input: > 10 kΩ
All Outputs: 120 Ω

Equalizer

High: +15 dB @ 12 kHz
Mid: +12 dB @ 2.5 kHz
Low: +15 dB @ 80 Hz

Crosstalk

Input to Output: < -82 dB @ 1 kHz
Adjacent Inputs (Channels 1–6): < -70 dB @ 1 kHz
Adjacent Inputs (Channels 7/8–11/12): < -68 dB @ 1 kHz

Main Mix Output

Line Output: 0 dBu (+2 dBu), balanced
Mic Output, Mono Output: 0 dBu (+2 dBu), unbalanced
Maximum Output: +21 dBu (balanced/unbalanced, 1/4” jacks)
Noise (Bus): < -83 dB @ 20 Hz – 22 kHz

General Specifications

Power Connection: IEC
Input Voltage: 100V~, 110-120V~, 50/60Hz; 220-240V~, 50/60Hz or DC24V
Dimensions (W x D x H): 19.0” x 7.7” x 1.7” (483 x 195 x 44 mm)
Weight: 6.4 lbs (2.9 kg)
