Dynacord L3600FD DSP Power Amplifier
Click to enlarge
Dynacord L3600FD DSP Power Amplifier

Dynacord L3600FD DSP Power Amplifier- 2 x 1,800W

The Dynacord L3600FD L-Series FIR-Drive Power Amplifier is a 3600W audio amplifier designed for performing musicians and production companies providing sound reinforcement for live performances in venues including music clubs, community hall events, performance centers, and sports venues

SKU: L3600FD Brand:

100% Genuine Products Only

We sell the products from the world's renowned brands only.

Talk to our Sales Expert

Original price was: ₨ 247,859.0.Current price is: ₨ 243,500.0.

Compare
Add to wishlist
19 People watching this product now!
  • Self-pick-up from our Shop

Pick up from our Bouddha Store

Free

  • Delivery within the Kathmandu Valley

Our courier will deliver to the specified address

1-12 Hours

Pathao/Indrive

  • Aramex Delivery Courier delivery

Aramex courier will deliver to your specified address

1-2 Days

"Fees vary based on geographical location."

  • Warranty Warranty 1 year

More details

  • Genuine & Original Product

More details

Payment Methods:

Description

If you’re searching for a feature-laden 2-channel power amplifier for your live sound rig, the Dynacord L3600FD DSP Power Amplifier fit. This roadworthy power amp vaunts an ultra-robust power supply, powerful linear design, bulletproof voltage handling, and sophisticated protection circuitry for indefatigable reliability. The L3600FD’s Sonicue-powered DSP supplies you with top-shelf 10-band PEQs and a world-class array processing section. You also get a premium-grade FIR drive that optimizes factory loudspeaker settings for first-class performance. Ideal for music clubs, community hall events, performance centers, sports venues, and touring performers, you’ll get your money’s worth out of the Dynacord L3600FD.

Dynacord L3600FD DSP Power Amplifier

L3600FD DSP Power Amplifier Features:

  • Live performance DSP amplifier, SpeakOn connectors
  • Fully integrated professional speaker processing with FIR Drive technology
  • Professional acoustic performance and rock-solid reliability
  • Powerful and proven audio performance
  • Engineered for constant stability at 2 Ohms
  • Sophisticated protection circuitry always protects the amplifiers and connected loudspeakers
  • High-performance bulletproof voltage handling
  • On-board DSP includes multi-band PEQs, crossovers, limiters and delay per channel; True channel grouping control with extra DSP capabilities including GEQ
  • Intuitive, powerful control software makes configuration and real time control easy. Up to 16 amp channels can be controlled and monitored simultaneously
  • Advanced FIR drive to optimize loudspeaker settings, providing premium features into an installation form factor
  • Engineered in Germany





With a commitment to provide  top-notch customer service and competitive prices, Audio Shop Nepal is the go-to destination for many audio enthusiasts in Nepal looking to purchase Dynacord products.

Specification

Dynacord L3600FDSpecs

Load Impedance
2 Ohms 2.7 Ohms 4 Ohms 8 Ohms
Maximum Output Power
Single Channel 2 Ohms: 3200 W 2.7 Ohms: 2700 W 4 Ohms: 1800 W 8 Ohms: 950 W Dual Channel 2 Ohms: 3000 W 2.7 Ohms: 2500 W 4 Ohms: 1700 W 8 Ohms: 900 W Bridged 4 Ohms: 6000 W 8 Ohms: 3400 W
Maximum RMS Voltage Swing
90.6 V
Voltage Gain
32.0 dB (ref 1 kHz)
IMD SMPTE
IMD-SMPTE, 60 Hz, 7 kHz: < 0.1%
DIM 30
< 0.05% (3.15 kHz, 15 kHz)
Maximum Input Level
+21 dBu
Crosstalk
< -80 dB (ref. 1 kHz, at 100 W / 4 Ohms)
Frequency Response
10 Hz to 21 kHz (±1 dB)
Input Impedance
20 kOhms
Signal-to-Noise Ratio (SNR)
> 109 dB (A-Weighted)
Output Noise
< -68 dBu (A-Weighted)
Total Harmonic Distortion
< 0.05% (at 1200 W / 4 Ohms MBW = 80 kHz, 1 kHz)
Topology
Class-H
Signal Processing
FIR filters Audio limiters Output delay per channel 31-band GEQ per channel PEQ per channel Load impedance
Protection
Audio limiters High temperature DC HF Back-EMF Peak current limiter Inrush current limiters Turn on delay
Cooling
Front-to-rear, 3-stage fans
Safety Class
I
Color
Black
Operating Temperature
40 to 105°F / 4 to 41°C
Power
Power Requirement: 120 VAC, 60 Hz Power Consumption: 850 W (1/8 maximum output power @ 4 Ohms) Mains Fuse: T20AH
Dimensions
3.5 x 19.0 x 18.2" / 88.9 x 482.6 x 462.3 mm
Weight
40.1 lb / 18.2 kg
