Blackmagic Design ATEM Mini Extreme ISO

The Blackmagic Design Blackmagic Design ATEM Mini Extreme ISO, one of the most complete video mixers in its price range, has built-in individual input recording. It’s one of the top livestreaming and video creation tools, according to industry professionals. This 8-in/2-out video mixer has all the capabilities of the original ATEM Mini Extreme plus DaVinci project file and Blackmagic RAW file relinking for fast post-production editing. The ATEM Mini Extreme ISO is ideal for business, gaming, eSports, investing, education, and more with to its eight HDMI inputs, Ethernet streaming, direct recording to USB flash drives, USB webcam connection, and more. The ATEM Mini Extreme ISO provides professional broadcasting and production capabilities for a variety of applications in a compact, easy-to-use package. A Fairlight audio mixer with EQ and dynamics is included.

Output

You can output using the Ethernet connection to your network or use the USB Type-C output to have your switched show recognized as a webcam input by virtually any video software such as Zoom, Microsoft Teams, Skype, Open Broadcaster, XSplit Broadcaster, and others.

4G and 5G Phone Suppor

The ATEM Mini Extreme versions may utilise mobile data from an Apple or Android phone through the USB connector for live production. If your hardwired Ethernet connection fails, it’s a wonderful backup. The switcher will automatically use the phone as the main connection, and the USB connector will power your phone to save battery.

Multiview Monitoring

You can configure the HDMI output for multiview with 4, 7, 10, 13, up to 16 views including Program, Preview, eight HDMI inputs, SuperSource, clean feed, media player, streaming status, recording status, and audio meters.

Camera Control

The ATEM Mini Extreme ISO can control the Blackmagic Pocket Cinema Camera 4K and 6K models when they are updated to the latest software and plugged in via the HDMI inputs. You can control your HDMI camera settings such as iris, gain, focus, detail, and zoom control on compatible lenses. Plus, you can color balance cameras, as well as create unique looks using the DaVinci Resolve primary color corrector built into the Blackmagic Pocket Cinema Camera 4K and 6K.

Media Pool

The switcher can store up to 20 images with fill and key, and it supports PNG, TGA, BMP, GIF, JPEG, and TIFF file formats.

Compatibility

It includes the ATEM Software Control Panel, and it is also compatible with the ATEM 1 M/E, ATEM 2 M/E, and ATEM 4 M/E Advanced Panels. The ATEM Mini Extreme ISO can be configured using Blackmagic’s Videohub Hardware Panel Setup utility to route sources to destinations using Videohub Smart Control Pro and Videohub Master Control Pro.

Recording

The ATEM Mini Extreme models support the direct recording of your streaming data to USB flash disks using the same H.264 video files with AAC audio that you streamed. The Mini Extreme ISO also allows you to record the eight input video channels as MP4 files. This allows you to directly upload to any online video site, such as YouTube or Vimeo. Recording to multiple disks is also supported via a USB hub or the Blackmagic MultiDock, so when a disk becomes full, recording can continue to a second disk for nonstop recording. Record settings and disk selection are set up in ATEM Software Control, and there’s a record status view in the built-in multiview. You can even trigger recording on connected Blackmagic Pocket Cinema Cameras.

DaVinci Resolve Integration

The Mini Extreme ISO stores a DaVinci Resolve project file, so you can edit your live production in one click. Loading all cuts, dissolves, and media pool visuals lets you edit your live production utilizing recorded input material. Relink Blackmagic Raw camera files to use DaVinci Resolve’s color correction.

Video Effects

One of the benefits of ATEM Mini is the professional production values possible using the range of built-in video effects. The cut button ensures an instant cut when switching between sources. The auto button is a professional term used on large broadcast switchers to enable video effect transitions. There are duration buttons for video effects allowing 0.5-, 1-, 1.5-, and 2-second settings. You can also select the type of effect you want including mix, which does a smooth transition between sources, and dip, which fades via a color during the transition. Or use fun DVE effects that move the image off-screen when transitioning between sources.

Audio

You may attach desktop and lapel microphones or a music player to play introductory music once the live broadcast begins. Interviews may include a host and guest using lapel microphones using two stereo audio inputs. All ATEM Mini audio inputs include panel buttons for audio volume adjustment and audio mixer input. All versions include a Fairlight audio mixer with all HDMI inputs and both microphone inputs for live mixing from all audio sources. ATEM Mini Extreme has a headphone output.

Broadcast Features

Hiding in the ATEM Mini Extreme models are a host of broadcast-caliber features that are accessible when connected to a Mac or Windows computer running the free ATEM Software Control app.

Blackmagic Design ATEM Mini Extreme ISO Features:

• 8 HDMI inputs and 2 HDMI outputs
• Direct livestream to your favorite platforms like YouTube, Twitch, Facebook Live, and more via the built-in streaming hardware
• Connect via USB to Apple or Android phones for their 5G or 4G mobile data
• Record easily to USB flash disks in H.264 video files and AAC audio
• Cut and Auto buttons employ transitions like dissolve, dip to color DVE squeeze, DVE push, and more
• Toggle between “cut bus” mode and “program/preview” mode
• Fairlight audio mixer allows you to keep your input audio perfectly mixed live
• Use for business presentations that utilize a PowerPoint with Skype, Zoom, Microsoft Teams, and more
• eSports events stream excellently thanks to 60 fps that eliminates lagging and makes for ultra-clear picture
• Investors and Kickstarter presenters can easily connect cameras for plenty of differing shots
• Use the professional multiview to monitor your inputs, preview, and program
• Advanced Chroma Key lets you use powerful green screen keying effects
• Even more extended features lie at your fingertips through the ATEM Software Control app for Mac/Windows
